The Nd:YAG laser radiates the light of specific wavelengths in high peak energy pulse,and in ultrashort nanosecond the light penetrates the tissue and is absorbed by the pigment and result in an instantaneous blast. The pigment particles are shattered into fragments, parts of them will be bounced out of the skin and the other parts will be spilt into tiny particles that can be engulfed by phagocytes and then eliminated by lymphatic system.
Treatment ranges:
1. All colors of tattoo removal.
2. Spots removal (freckle, coffee spots, age spots, nevus of Ota).
3. Embroidery lipline.
4. Eyeline, eyebrow pigments removal.
Working heads:
1.532nm: for treatment of epidermal pigmentation such as freckles, solar lentiges, epidermal melasma, etc.
2.1064nm: for treatment of tattoo removal, dermal pigmentation and treating certain pigmentary conditions such as Nevus of Ota and Hori’s.
3. (1320nm):for treatment of blackhead removal, skin tightening and whitening, skin rejuvenation, wrinkle removal, shrink pores, acne treatment.
Function:
1.Pigment dispelling.
2.Tattoo removal: can remove black, blue, brown and red tattoo pigments on eyebrow, eyeline, lipline and other parts of the body.
3.Skin rejuvenation:laser facial, large pore reduction,face whitening.
4.Eliminate the age pigment, spot, birthmark, and pigment changes etc.
| Wavelength | 1320nm & 1064nm & 532nm |
| Energy | 1-2000mJ |
| Laser Type | Q-switched Nd:YAG |
| Spot Size | 2-8mm |
| Repetition Rate | 1-10Hz |
| Pulse Width | <10ns |
| YAG Bar Size | 6 |
| Power | 800W |
| Aiming Beam | 5mW red diode laser, 635 nm |
| Stand-by Working | Continuously for 12 hours |
| Cooling | Self-contained, closed water cycle |
| Display | 4.3 inches touch screen |
| Electrical Requirements | 100-240VAC, 50/60Hz |
